Intel® Core™ i7 processor 14700K 33M Cache, up to 5.60 GHz

Model:
Intel® Core™ i7-14700K

Processor Type:
PC/Client/Tablet, Workstation

General Specifications:

* Launch Date: Q4'23
* Socket: FCLGA1700
* Embedded Options Available: No

Performance Details:

* Cores / Threads: 20 Cores (8 Performance-cores, 12 Efficient-cores) / 28 Threads
* Performance-core Base Frequency: 3.4 GHz
* Max Turbo Frequency: 5.6 GHz
* Cache: 33 MB Intel® Smart Cache
* L2 Cache: 28 MB
* Processor Base Power: 125 W
* Maximum Turbo Power: 253 W
* Max Operating Temperature (Tjunction): 100°C

Memory Specifications:

* System Memory: Up to 192 GB (2 Channels)
* Memory Types: Up to DDR5 5600 MT/s, Up to DDR4 3200 MT/s
* Max Memory Bandwidth: 89.6 GB/s
* ECC Memory Supported: Yes

Integrated Graphics:

* Graphics Model: Intel® UHD Graphics 770
* Graphics Base / Max Frequency: 300 MHz / 1.6 GHz
* Execution Units: 32
* Max Resolution (HDMI): 4096 x 2160 @ 60Hz
* Max Resolution (DP): 7680 x 4320 @ 60Hz
* Max Resolution (eDP): 5120 x 3200 @ 120Hz
* Supported APIs: DirectX 12, OpenGL 4.5, OpenCL 3.0
* Displays Supported: 4
* Features: Intel® Quick Sync Video, Intel® Clear Video HD Technology, Multi-Format Codec Engines (2)

Expansion Options:

* PCI Express® Revision: 5.0 and 4.0
* PCI Express Configurations: Up to 1x16+4, 2x8+4
* Max # of PCI Express Lanes: 20
* Direct Media Interface (DMI) Revision: 4.0 (Max 8 Lanes)

Advanced Technologies:

* Intel® Hyper-Threading Technology: Yes
* Instruction Set: 64-bit (Extensions: Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2)
* Intel® Virtualization: VT-x, VT-d, VT-x with Extended Page Tables (EPT), VT-rp
* Other Technologies: Intel® Thread Director, Intel® Speed Shift Technology, Enhanced Intel SpeedStep® Technology, Intel® Gaussian & Neural Accelerator 3.0, Intel® Deep Learning Boost, Intel® Turbo Boost Max Technology 3.0, Intel® Volume Management Device (VMD), Idle States, Thermal Monitoring Technologies

Security & Reliability:

* Intel vPro® Eligibility (Enterprise, Essentials, Platform)
* Intel® Threat Detection Technology (TDT)
* Intel® Active Management Technology (AMT)
* Intel® Standard Manageability (ISM)
* Intel® Remote Platform Erase (RPE)
* Intel® One-Click Recovery
* Intel® Hardware Shield Eligibility
* Intel® Secure Key
* Intel® Control-Flow Enforcement Technology
* Intel® Total Memory Encryption - Multi Key
* Intel® AES New Instructions
* Intel® OS Guard
* Intel® Trusted Execution Technology
* Execute Disable Bit
* Intel® Boot Guard
* Mode-based Execute Control (MBEC)
* Intel® Stable IT Platform Program (SIPP)

Package Specifications:

* Thermal Solution Specification: PCG 2020A
* Package Size: 45.0 mm x 37.5 mm
