CPU:
LGA1700 Socket: Supports 14th, 13th, and 12th Gen Intel® Core™, Pentium® Gold and Celeron® Processors
Chipset:
Intel® B760 Express Chipset
Memory:
2 x DDR4 DIMM sockets, max. 64GB
Supports up to 3200 MT/s
Non-ECC Un-buffered DIMM (ECC modules operate in non-ECC mode)
Dual channel memory architecture, Supports XMP
Graphics:
1 x D-Sub (Supports max. 1920x1200@60 Hz)
1 x HDMI port (Supports max. 4096x2160@60 Hz, HDMI 2.1, HDCP 2.3)
Expansion Slots:
CPU: 1 x PCIe 4.0 x16 slot (x16 mode)
Chipset: 1 x PCIe 3.0 x1 slot
Storage:
Supports 2 x M.2 slots and 4 x SATA 6Gb/s ports
M.2_1 (CPU): Type 2280 (Supports PCIe 4.0 x4/x2)
M.2_2 (Chipset): Type 2280 (Supports PCIe 4.0 x4/x2)
RAID Support: RAID 0/1/5/10 for SATA storage devices
Ethernet:
Realtek® GbE LAN chip (1 Gbps/100 Mbps)
USB:
Rear USB (Total 6 ports): 4 x USB 3.2 Gen 1, 2 x USB 2.0/1.1
Front USB (Total 6 ports): 1 x USB 3.2 Gen 1 header (2 ports), 2 x USB 2.0/1.1 headers (4 ports)
Audio:
Realtek® Audio CODEC, High Definition Audio
Supports 2/4/5.1/7.1-channel playback, S/PDIF Out
Back Panel I/O Ports:
2 x USB 2.0/1.1
1 x D-Sub
1 x HDMI
4 x USB 3.2 Gen 1
1 x RJ-45 LAN port
3 x Audio jacks
Internal I/O Connectors:
Fan/Cooling: 1x CPU Fan, 2x System Fan
Power: 1x 24-pin Main, 1x 8-pin ATX 12V
Storage: 2x M.2 slots, 4x SATA 6Gb/s
USB: 1x USB 3.2 Gen 1 header, 2x USB 2.0/1.1 headers
Misc: 1x RGB LED, 1x Front Panel, 1x Front Audio, 1x S/PDIF Out header, 1x TPM header, 1x Serial Port header, 1x Clear CMOS jumper
Special Features / H/W:
iTE® I/O Controller, H/W Monitoring (Voltage, Temperature, Fan, Water cooling flow), GIGABYTE Control Center (GCC), Q-Flash
Software & BIOS:
1 x 128 Mbit flash, AMI UEFI BIOS, Norton® Internet Security (OEM), LAN bandwidth management software
