CPU:
LGA1700 Socket: Supports 14th, 13th, and 12th Gen Intel® Core™, Pentium® Gold and Celeron® Processors
Chipset:
Intel® H610 Express Chipset
Memory:
2 x DDR4 DIMM sockets, max. 64GB
Supports up to 3200 MT/s
Non-ECC Un-buffered DIMM (ECC modules operate in non-ECC mode)
Dual channel memory architecture, Supports XMP
Graphics:
1 x HDMI port (Supports max. 4096x2160@60 Hz, HDMI 2.1, HDCP 2.3)
Expansion Slots:
CPU: 1 x PCIe 4.0 x16 slot (x16 mode)
Chipset: 1 x PCIe 3.0 x1 slot
Storage:
Supports 1 x M.2 slot and 2 x SATA 6Gb/s ports
M.2 (Chipset): Type 2280/2260 (Supports PCIe 3.0 x4/x2)
Ethernet:
Realtek® GbE LAN chip (1 Gbps/100 Mbps/10 Mbps)
USB:
Rear USB (Total 6 ports): 2 x USB 3.2 Gen 1, 4 x USB 2.0/1.1
Front USB (Total 4 ports): 1 x USB 3.2 Gen 1 header (2 ports), 1 x USB 2.0/1.1 header (2 ports)
Audio:
Realtek® Audio CODEC, High Definition Audio
Supports 2/4/5.1/7.1-channel playback
Back Panel I/O Ports:
1 x HDMI
2 x USB 3.2 Gen 1
4 x USB 2.0/1.1
1 x RJ-45 LAN port
3 x Audio jacks
Internal I/O Connectors:
Fan/Cooling: 1x CPU Fan, 1x System Fan
Power: 1x 24-pin Main, 1x 8-pin ATX 12V
Storage: 1x M.2 slot, 2x SATA 6Gb/s
USB: 1x USB 3.2 Gen 1 header, 1x USB 2.0/1.1 header
Misc: 1x Front Panel, 1x Front Audio, 1x TPM header, 1x Clear CMOS jumper
Special Features / H/W:
iTE® I/O Controller, H/W Monitoring (Voltage, Temperature, Fan, Water cooling flow), APP Center, Q-Flash
Software & BIOS:
1 x 128 Mbit flash, AMI UEFI BIOS, Norton® Internet Security (OEM)
