CPU:
AMD Socket AM5 for AMD Ryzen™ 9000 / 8000 / 7000 Series Processors
Chipset:
AMD A620
Memory:
2 x DDR5 DIMM sockets, max. 128GB
Supports up to 6400+MT/s (OC)
Non-ECC Un-buffered DIMM
Dual channel memory architecture, Supports AMD EXPO™ & XMP
Graphics:
1 x D-Sub (Supports max. 1920x1200@60 Hz)
1 x DisplayPort (Supports max. 3840x2160@144 Hz, DP 1.4)
1 x HDMI port (Supports max. 4096x2160@60 Hz, HDMI 2.1, HDCP 2.3)
Supports up to 3 displays simultaneously
Expansion Slots:
AMD Ryzen™ 7000 Series: 1 x PCIe 4.0 x16 slot (x16 mode)
AMD Ryzen™ 8000 Series (Phoenix 1): 1 x PCIe 4.0 x16 slot (x8 mode)
AMD Ryzen™ 8000 Series (Phoenix 2): 1 x PCIe 4.0 x16 slot (x4 mode)
AMD A620 Chipset: 1 x PCIe 3.0 x1 slot
Storage:
Supports 1 x M.2 slot and 4 x SATA 6Gb/s ports
M.2_1 (CPU): Type 2580 (Supports PCIe 4.0 x4/x2)
AMD RAID Support: RAID 0/1/10 for NVMe & SATA storage devices
Ethernet:
Realtek® GbE LAN chip (1 Gbps/100 Mbps/10 Mbps)
USB:
Rear USB (Total 6 ports): 2 x USB 3.2 Gen 1, 4 x USB 2.0/1.1
Front USB (Total 6 ports): 1 x USB 3.2 Gen 1 header (2 ports), 2 x USB 2.0/1.1 headers (4 ports)
Audio:
Realtek® Audio CODEC, High Definition Audio
Supports 2/4/5.1/7.1-channel playback
Back Panel I/O Ports:
4 x USB 2.0/1.1
2 x USB 3.2 Gen 1
1 x PS/2 keyboard/mouse port
1 x D-Sub
1 x DisplayPort
1 x HDMI
1 x RJ-45 LAN port
3 x Audio jacks
1 x Q-Flash Plus button
Internal I/O Connectors:
Fan/Cooling: 1x CPU Fan, 2x System Fan
Power: 1x 24-pin Main, 1x 8-pin ATX 12V
Storage: 1x M.2 slot, 4x SATA 6Gb/s
USB: 1x USB 3.2 Gen 1 header, 2x USB 2.0/1.1 headers
Misc: 1x Addressable LED, 1x RGB LED, 1x Front Panel, 1x Front Audio, 1x TPM header, 1x Clear CMOS jumper
Special Features / H/W:
iTE® I/O Controller, H/W Monitoring (Voltage, Temperature, Fan, Water cooling flow), GIGABYTE Control Center (GCC), Q-Flash, Q-Flash Plus
Software & BIOS:
1 x 256 Mbit flash, AMI UEFI BIOS, Norton® Internet Security (OEM), LAN bandwidth management software
